SLR-342VR3F
LED Uni-Color Red 650nm 2-Pin T-1 Bulk
廠商型號:
SLR-342VR3F
芯天下內部編號:
293-SLR-342VR3F
生產廠商:
rohm semiconductor
描述:
LED Uni-Color Red 650nm 2-Pin T-1 Bulk
產品類別:
Lighting|LEDs
所示圖像僅為示意圖,。請從產品數據表中獲得準確的規格,。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Package | 2T-1 |
| Pin Count | 2 |
| Type | Uni-Color |
| Number of LEDs | 1 |
| Intensity | 16 mcd |
| Dominant Wavelength/Color Temperature | 630 nm |
| Peak Wavelength | 650 nm |
| Color | Red |
| Lens Appearance | Colored Diffused |
| Lens Shape Type | Circular |
| Viewing Angle | 40 ° |
| Mounting Orientation | Top Mount |
| Mounting | Through Hole |
| Standard Package | Bulk |
| Product Category | Standard LEDs - Through Hole |
| RoHS | RoHS Compliant |
| Illumination Color | Red |
| Luminous Intensity | 16 mcd |
| Wavelength/Color Temperature | 650 nm |
| Lens Color/Style | Tinted, Diffused |
| LED Size | 3.1 mm |
| Packaging | Bulk |
| Lens Shape | Circular |
| Mounting Style | Through Hole |
| Factory Pack Quantity | 2000 |
| Voltage - Forward (Vf) Typ | 2V |
| Mounting Type | Through Hole |
| Lens Style/Size | Round with Domed Top, 3.1mm |
| Wavelength - Dominant | 630nm |
| Millicandela Rating | 16mcd |
| Current - Test | 10mA |
| Height | 5.20mm |
| Lens Type | Diffused, Tinted |
| Package/Case | Radial |
| rohs | Lead free / RoHS Compliant |
| Emission angle | 40 ° |
| Automotive | NO |
| Surface colour | DIFFUSED |
| Emitted colour | RED |
| Case type | LOW POWER |
| Forward voltage | 2.1 V |
| Lumintenmin | 5.6 mcd |
| Number of chips | 1 |
| Leadfree Defin | RoHS-conform |
| Case size | 3 LxW |
| I(F) nominal | 10 mA |
| Lambda domtyp | 650 nm |
| Lambda peak typ | 650 nm |
